CAPACITY

5

10

20

30

50

80

100

150

Crank Dia.

48 mm

60 mm

76 mm

83 mm

95 mm

102 mm

127 mm

139 mm

Stroke Length

38 mm

51 mm

75 mm

75 mm

100 mm

114 mm

127 mm

127 mm

No. of Stroke

80 pm

70 pm

65 pm

60 pm

50 pm

40 pm

30 pm

25 pm

Hole of Ram

20 mm

25 mm

32 mm

38 mm

45 mm

51 mm

51 mm

57 mm

Bed Size

330x175

405x255

505x305

555x380

750x520

775x550

815x585

965x685

Bed to Ram Dist.

180 mm

225 mm

295 mm

355 mm

400 mm

455 mm

505 mm

560 mm

Floor to Bed

610 Apr.

725 Apr.

750 Apr.

755 Apr.

775 Apr.

775 Apr.

755 Apr.

800 Apr.

All-over Size

1500x500

1700x600

1900x800

2050x900

2350x1000

2500x1350

2750x1500

3050x1600

Motor Required

0.5 HP

1 HP

2 HP

3 HP

5 HP

7.5 HP

10 HP

15 HP

Approx Weight

300 Kgs.

550 Kgs.

1050 Kgs.

1400 Kgs.

2600 Kgs.

4300 Kgs.

5800 Kgs.

6800 Kgs.
